Signal Generator TAG101 Audio Generator

This is the Signal Generator TAG101 Audio Generator which 10Hz-1MHz Low-Frequency Signal for Maintenance 220V. It is a physics lab apparatus, needed for physics experiments.

100% brand new and high-quality
A reliable circuit system ensures high stability and accuracy
This device is easy to use due to vertical panel integration
The frequency range 10hz-1mhz is optional on the signal generator panel
This generator has characteristics of a sine wave and an effective frequency response
It’s the instant for electronic engineering, laboratories, production lines, teaching, and scientific research. It can also be used as a supporting module for industrial equipment.
Specification of Signal Generator TAG101:
Condition: 100% Brand New
Item Type: Audio Generator
Frequency Range: 10Hz to 1MHz, 5 Measuring Ranges
Accuracy: ±5% of full scale
Output Impedance: 600Ω
Output Control: 0dB, -10dB, -20dB, -30dB, -40dB, -50dB fine adjustment.
Sine Wave Output:
Output Voltage: 5-6V RMS
Distortion:
500Hz-50kHz, no more than 0.05%
50Hz-500kHz, no more than 0.5%
Output Smoothness: Take 1 for reference, ±1.5dB
Square Wave Output: Range: 10Hz-1MHz
Output Level: 10V Peak Value
Rise: 0.5μs
Synchronization Performance: Range: 1V voltage per output can change the oscillation frequency by 1%
Input Impedance: 10KΩ
Power Supply: 220V (50/60Hz), 8W
Plug: EU Plug
Made in China
This is not a Function Generator
Signal Generator TAG101 Audio Generator Details
